NAVED AHMAD NAZ

Bridge and Structural Design Engineer with over 10 years of specialized experience in structural analysis and design of diverse concrete and steel structures. Proven track record includes residential apartments, commercial buildings, educational facilities, and complex infrastructures such as post-tensioned bridges and flyovers. Expertise includes advanced FEA structural modeling, comprehensive design documentation, and meticulous project specifications, ensuring compliance with industry standards and codes. Proficient in leading software tools like SAP2000, ETABS, and AutoCAD, delivering precise and efficient designs that meet rigorous safety and quality benchmarks.

• Member of Pakistan Engineering Council (Civil/35605)
• Member of Pakistan Society of Civil Engineers

• Analysis and external stability of luffing jib tower cranes (10-to-18-ton capacity with 25 m height and 55 m jib length) for wind (160 Km/h) considering different attack angles and moment generated from un-balanced loads in “In service” & “out of service” cases. Design of foundations for analysis cases for anchored (fixing angles) and un-anchored shafts (balanced by base ballast weight). Design of foundations for additional super imposed dead loads from bridge deck scaffolding load and vehicle movement over partial footing based on Eurocodes and Using In-house developed excel sheets and Tekla Tedds.
• Developed a structural assessment report for the temporary bearing plate replacement following the prestressing stage during bridge construction. A detailed FEA model of the entire 5-span box girder bridge was created in CSI Bridge to evaluate the effects of jacking displacements on adjacent bearings and to determine the corresponding jack loads.
• Design of structural steel assembly inserted into lifting fork to remove the bridge gantry braced I beams under the bridge deck using CSI SAP.
• Design of temporary shoring system using steel I beams with concrete laggings to support the excavation of 4 m for pile caps using Geo5 and Tekla based on Eurocode.
• Design of shoring system of sheet piles with struts for jacking and receiving shafts for micro tunnel boring machine to avoid water seepage due to high water table level using DeepEX.
• Performed analysis of the central 58 m span box girder for Stage-I prestressing to evaluate top and bottom fiber stresses and deflections under dead load and partial prestressing, using an in-house developed Excel tool and CSI Bridge in accordance with AASHTO LRFD. The objective was to verify whether the scaffolding beneath the 16.15 m wide multicell box girder could be safely removed after completion of Stage-I prestressing.
• Performed 5 span cast in place 3 cell box girder bridge analysis for stressing stage-I & II with the presence of temporary openings in the central 58 m span for luffing crane (In cantilever) and jack lowering (3 openings in top slab, 1 in each cell) and checked the bridge deck capacities (Stresses and Moments) considering self-weight & barrier load. The results shows that the moment resistance and stresses at top fiber of bridge deck are within permissible limits of AASHTO LRFD Bridge Design Specifications.
• Review of Shop drawings and BBS as per issued for construction drawings from the design consultant.

Project: Construction of Model Prison at H-16, Islamabad, Client: CDA, Islamabad, Performed detailed analysis and design of various structural components, including the administration building, prisoner barracks, hospital, central watch towers, overhead and underground water tanks, residential buildings, and a 20 ft. high RCC boundary wall. Utilizes software tools such as SAP2000, SAFE, ASDIP Retain, ASDIP Foundation, and Excel for structural analysis and design calculations. Ensured compliance with the provisions of BCP 2021, ACI 318, ACI 35R, and ASCE 7 standards throughout the design process., Project: Structural Design of 3 Story Industrial Building in Kasur, Client: Prime Tolling Company Pvt., As a structural engineer involved in the detailed seismic and Finite element analysis and earthquake resistant design of RCC frame structure building with applicable design codes and specifications, structural design calculations and development of construction drawings. Coordination with client and site visits., Project: Structural Design of 3 Story Industrial Building in Sundar Industrial State Lahore, Client: Arber Pharma, Lahore, As a structural engineer involved in the detailed seismic and finite element analysis and earthquake resistant design of RCC frame structure building with applicable design codes and specifications, structural design calculations and development of construction drawings., Project: Detailed Design of Gabral Kalam Hydropower Project (88 MW), Client: Pakhtunkhwa Energy Development Organization (PEDO), Detailed seismic and finite element analysis and design considering special moment resisting frames buildings of Employer’s Colony with 4 story apartment buildings provided with raft footing, having Steel structure roof trusses and Powerhouse control buildings & office following the provisions of Building Code of Pakistan, UBC-97, ACI 318, ASCE and AISC. Development of construction drawings and engineers estimate along with tender documents. Prepare the structural design calculations and design report. Attends meeting with client and site visits., Project: 8 Story Commercial Building at Tufail Road Saddar Bazar Cantt, Lahore, Client: Arch-En-Plan Associates Pvt. Ltd. Lahore, Complete structural seismic and finite element analysis, earthquake resistant design and development of construction drawings of 8 Story commercial building with 02 basements using SAP2000, SAFE-14, IES Quick Retaining Wall, ASDIP Retain and Excel Sheets, following the provisions of Building Code of Pakistan, UBC-97 Vol II, ASCE 7-10, ACI 318-19., Project: 6 Story Commercial Building at Block C, Phase VI, DHA, Lahore, Client: Arch-En-Plan Associates Pvt. Ltd. Lahore, Complete structural seismic and finite element analysis, earthquake resistant design and development of construction drawings of 6 Story commercial building using SAP2000, SAFE-14, IES Quick Retaining Wall, ASDIP Retain and Excel Sheets, following the provisions of Building Code of Pakistan, UBC-97 Vol II, ASCE 7-10, ACI 318-19., Project: Quaid-e-Azam Apparel Park (QAAP), Sheikhupura, Pakistan, Client: Punjab Industrial Estates, Design and development of tender and construction drawings for buildings and road structures including office building, food court, masjid building, bridges, culverts, roadside drains, underground disposal tanks and other related structures using CSI Bridge and SAP2000, following the provisions of Pakistan Building Code-2007, ACI 318-14, ACI 350-R, UBC-97, AASHTO LRFD Bridge Design Specifications and West Pakistan Code of Practice for Highway and Bridges 1967., Project: Development of Play Fields in District Lahore, Pakistan, Client: Punjab Sports Board, Structural Design of various sports structures including pavilions, administration buildings and flood light poles using SAP2000 following the provisions of Pakistan Building Code-2007, ACI 318-14 and UBC-97., Project: Finance and Trade Center (8 Story) Johar Town, Lahore, Pakistan, Client: Lahore Development Authority, Design of eight story RCC apartment building with two overhead water tanks of 250000 gallons each on entire covered area using SAP2000 following the provisions of ACI 318-14, ACI 350-R and UBC-97., Project Fruit and Vegetable Market Kacha, Lahore, Pakistan, Client: Government of Punjab, Design of 3 story RCC frame structure for cold storage and bank building using SAP 2000, following the provisions of ACI 318-11 and UBC-97., Project: Punjab Police Integrated Command Control & Communications (PPIC3) Centre Adopted at Multan, Gujranwala, Rawalpindi & Faisalabad, Client: Planning & Design Directorate Punjab Buildings Department Lahore, Structural analysis, design and development of construction drawings of 3 Story PPIC3, CPO buildings and overhead water tanks using SAP2000, SAFE-14, IES Quick Retaining Wall and Excel Sheets, following the provisions of Building Code of Pakistan, UBC-97 Vol II, ASCE 7-10, ACI 318-14., Many residential projects with area 5 Marla, 10 Marla, 1 Kanal and 2 Kanal., REAHBILITATION, RETROFITTING & STRUCTURAL ASSESMENT PROJECTS:, Khadim-e-Punjab Bahria Model School and College, Gwadar, Client: Punjab Education Department, As a structural engineer, involved in the finite element analysis and special moment resisting frame design and retrofitting of existing frame structure educational building. Develops the detailed construction drawings for retrofitting, structural design reports, BOQ and engineer estimates. Building mainly includes SMRF RCC frame structure with academic and administration blocks., Project: CAREC-Regional Improving Border Services (RIBS) Project, Chaman & Torkham-BCP, Client: FBR, Pakistan, As Senior Engineer Structures, involved in the assessment and retrofitting and review of different types of buildings for Chaman and Torkham Business Centre Projects. Attends the meetings with client and architecture, developed reports and manage correspondence. The buildings mainly include RCC frame structures and Pre-Engineered Steel structures in highly seismic zone. Project: Construction of Swat Motorway (Phase-II) From Chakdara to Fatehpur (80 Km), Client: Pakhtunkhwa Highway Authority, Detailed analysis and design of all road structures including bridges (Straight and Curved), flyovers, underpasses, subways, cattle creeps, pipe culverts, box culverts, and retaining walls using CSI Bridge, SAP2000, IES Quick Retaining Wall, ASDIP Retain, ASDIP Foundation, ET Culvert and Excel Sheets, following the provisions of AASHTO LRFD Bridge Design Specifications 2012, UBC-97 Vol II, ACI 318-19, West Pakistan Code of Practice for Highway and Bridges 1967., Project: Feasibility Study and Detailed Design of Roads, Sibi Zone/Sibi Cluster, Balochistan, Client: Communication Department, Government of Balochistan, Pakistan, Analysis and design of road structures including bridges, box culverts, pipe culverts and retaining walls using CSI Bridge, SAP2000, IES Quick Retaining Wall, ASDIP Retain, ASDIP Foundation, ET Culvert and Excel Sheets, following the provisions of AASHTO LRFD Bridge Design Specifications 2012, UBC-97 Vol II, ACI 318-19 and West Pakistan Code of Practice for Highway and Bridges 1967., Project: Central Asia Regional Economic Cooperation Corridors 5 and 6 (Salang Corridor), Client: Ministry of Public Works, Afghanistan, Analysis and design of road structures including bridges (Straight and Curved), avalanche galleries, box culverts, and retaining walls using CSI Bridge, SAP2000, IES Quick Retaining Wall, ASDIP Retain, ASDIP Foundation, ET Culvert and Excel Sheets, following the provisions of AASHTO LRFD Bridge Design Specifications 2012, UBC-97 Vol II, ACI 318-19, Afghanistan Bridge Design Code 2012., Project: Feasibility Study and Detailed Design for Construction of Mashkhel Panjgoor Road (200 KM), Client: NHA, Ministry of Communications, Pakistan, Analysis and design of road structures including bridges (Straight and Curved), interchanges, underpasses, box culverts, and retaining walls using CSI Bridge, SAP2000, IES Quick Retaining Wall, ASDIP Retain, ASDIP Foundation, ET Culvert and Excel Sheets, following the provisions of AASHTO LRFD Bridge Design Specifications 2012, UBC-97 Vol II, ACI 318-19 and West Pakistan Code of Practice for Highway and Bridges 1967., Project: Dualization of Khanewal - Lodhran Road, Length 94 Km, Client: Communication & Works Department Government of the Punjab, Design review of road structures including bridges, Interchange flyovers, culverts, underpasses and subways using CSI Bridge, SAP2000, IES Quick Retaining Wall and Excel Sheets, following the provisions of AASHTO LRFD Bridge Design Specifications 2012, UBC-97 Vol II, ASCE 7-10, ACI 318-14 and West Pakistan Code of Practice for Highway and Bridges 1967., Project: Peshawar-Karachi Motorway (Sukkhur-Multan Section - 392 Km), Client: National Highway Authority (NHA) Pakistan, Design review of road structures including bridges, culverts, underpasses, subways and cattle creeps using CSI Bridge, SAP2000, ET-Culvert and ASDIP RETAIN, following the provisions of AASHTO LRFD Bridge Design Specifications, UBC-97 Vol II, ASCE 7-10 West Pakistan Code of Practice for Highway and Bridges 1967., Project: Procurement of Plant, Design, Supply and Install of Chianwali Hydropower Project, Client: Punjab Power Management Unit, Energy Department,, Design review of hydropower structures including bridges, spillways and powerhouse using CSI Bridge, SAP2000 and excel sheets, following the provisions of AASHTO LRFD Bridge Design Specifications, UBC-97 Vol II, ASCE 7-10, ACI 318-14 West Pakistan Code of Practice for Highway and Bridges 1967, Project: Procurement of Plant, Supply and Install of Pakpattan Hydropower Project, Client: Punjab Power Management Unit, Energy Department,, Design review of hydropower structures including bridges using CSI Bridge, SAP2000 and excel sheets, following the provisions of AASHTO LRFD Bridge Design Specifications, UBC-97 Vol II, ASCE 7-10, ACI 318-14 and West Pakistan Code of Practice for Highway and Bridges 1967, Project: Dualization and Rehabilitation of Muridke-Narowal Road, Pakistan, Client: Punjab Highway Department, Supervision of road works and road structures including the preparation of bar bending schedules, shop drawings and bill of quantities for bridges, culverts and roadside drains., Project: Construction of Muridke-Narowal Over Head Bridge, Pakistan, Client: Punjab Highway Department, Supervision of road works and bridge structures including the preparation of bar bending schedules, shop drawings and bill of quantity
